Multi Node Test

Multi Node Test#

Multi-Node CI is designed to test distributed scenarios of very large models, eg: disaggregated_prefill multi DP across multi nodes and so on.

How it works#

The following picture shows the basic deployment view of the multi-node CI mechanism. It shows how the GitHub action interacts with lws (a kind of kubernetes crd resource).

alt text

From the workflow perspective, we can see how the final test script is executed, The key point is that the shared files tests/e2e/nightly/multi_node/scripts/lws.yaml.jinja2 and tests/e2e/nightly/multi_node/scripts/run.sh define the cluster template and pod entry script. Each node executes different logic according to the LWS_WORKER_INDEX environment variable, so that multiple nodes can form a distributed cluster to perform tasks. run.sh selects the pytest entrypoint from the config path: internal DP configs use internal_dp/scripts/test_multi_node.py, while external DP configs use external_dp/scripts/test_external_dp.py.

alt text

How to contribute#

  1. Upload custom weights

    If you need customized weights, for example, you quantized a w8a8 weight for DeepSeek-V3 and you want your weight to run on CI, uploading weights to ModelScope’s vllm-ascend organization is welcome. If you do not have permission to upload, please contact @Potabk

  2. Add config yaml

    For the normal internal DP multi-node flow, add the config yaml to tests/e2e/nightly/multi_node/internal_dp/config/, like DeepSeek-V3.yaml. External DP cases use the separate tests/e2e/nightly/multi_node/external_dp/config/ directory and should pass that directory through config_base_path in workflow or CONFIG_BASE_PATH locally.

    Suppose you have 2 nodes running a 1P1D setup (1 Prefillers + 1 Decoder):

    you may add a config file looks like:

    test_name: "test DeepSeek-V3 disaggregated_prefill"
# the model being tested
model: "vllm-ascend/DeepSeek-V3-W8A8"
# how large the cluster is
num_nodes: 2
npu_per_node: 16
# All env vars you need should add it here
env_common: &env_common
  VLLM_USE_MODELSCOPE: true
  OMP_PROC_BIND: false
  OMP_NUM_THREADS: 100
  HCCL_BUFFSIZE: 1024
  SERVER_PORT: 8080
disaggregated_prefill:
  enabled: true
  # node index(a list) which meet all the conditions:
  #  - prefiller
  #  - no headless(have api server)
  prefiller_host_index: [0]
  # node index(a list) which meet all the conditions:
  #  - decoder
  decoder_host_index: [1]

# Add each node's vllm serve cli command just like you run locally
# Add each node's individual envs like follow
deployment:
- name: prefiller node # optional: just for description, not used in code
  envs:
    <<: *env_common
    VLLM_ASCEND_ENABLE_FLASHCOMM1: 1
    # Continue to add other envs if needed
  server_cmd: >
    vllm serve ...
- name: decoder node # optional: just for description, not used in code
  envs:
    <<: *env_common
    VLLM_ASCEND_ENABLE_FLASHCOMM1: 1
    # Continue to add other envs if needed
  server_cmd: >
    vllm serve ...
benchmarks:
  perf:
    # fill with performance test kwargs
  acc:
    # fill with accuracy test kwargs

  3. Add the case to nightly workflow

Currently, the multi-node test workflow is defined in .github/workflows/schedule_nightly_test_a3.yaml.

```yaml
multi-node-tests:
  name: multi-node
  if: always() && (github.event_name == 'schedule' || github.event_name == 'workflow_dispatch')
  strategy:
    fail-fast: false
    max-parallel: 1
    matrix:
      test_config:
        - name: multi-node-deepseek-pd
          config_file_path: DeepSeek-V3.yaml
          size: 2
        - name: multi-node-qwen3-dp
          config_file_path: Qwen3-235B-A22B.yaml
          size: 2
        - name: GLM5_1-W8A8-EP-external
          config_file_path: GLM5_1-W8A8-EP-external.yaml
          config_base_path: tests/e2e/nightly/multi_node/external_dp/config/
          size: 4
  uses: ./.github/workflows/_e2e_nightly_multi_node.yaml
  with:
    soc_version: a3
    runner: linux-aarch64-a3-0
    image: 'swr.cn-southwest-2.myhuaweicloud.com/base_image/ascend-ci/vllm-ascend:nightly-a3'
    replicas: 1
    size: ${{ matrix.test_config.size }}
    config_file_path: ${{ matrix.test_config.config_file_path }}
    config_base_path: ${{ matrix.test_config.config_base_path || '' }}
    name: ${{ matrix.test_config.name }}
  secrets:
    KUBECONFIG_B64: ${{ secrets.KUBECONFIG_B64 }}
```

The matrix above defines all the parameters required to add a multi-machine use case. The parameters worth noting are size, config_file_path, and config_base_path. size defines the number of nodes required for your use case. config_file_path is the yaml file name, and config_base_path tells the loader which config directory to use. For internal DP cases, use an empty config_base_path so the loader uses its default internal DP config directory. For external DP cases, set it to tests/e2e/nightly/multi_node/external_dp/config/.

Run Multi-Node tests locally#

1. Use kubernetes#

This section assumes that you already have a Kubernetes NPU cluster environment locally. Then you can easily start our test with one click.

  • Step 1. Install LWS CRD resources

    See https://lws.sigs.k8s.io/docs/installation/ Which can be used as a reference

  • Step 2. Deploy the following yaml file lws.yaml as needed

    apiVersion: leaderworkerset.x-k8s.io/v1
kind: LeaderWorkerSet
metadata:
  name: test-server
  namespace: vllm-project
spec:
  replicas: 1
  leaderWorkerTemplate:
    size: 2
    restartPolicy: None
    leaderTemplate:
      metadata:
        labels:
          role: leader
      spec:
        containers:
          - name: vllm-leader
            imagePullPolicy: Always
            image: swr.cn-southwest-2.myhuaweicloud.com/base_image/ascend-ci/vllm-ascend:nightly-a3
            env:
              - name: CONFIG_YAML_PATH
                value: DeepSeek-V3.yaml
              - name: CONFIG_BASE_PATH
                value: tests/e2e/nightly/multi_node/internal_dp/config/
              - name: WORKSPACE
                value: "/vllm-workspace"
              - name: FAIL_TAG
                value: FAIL_TAG
            command:
              - sh
              - -c
              - |
                bash /vllm-workspace/vllm-ascend/tests/e2e/nightly/multi_node/scripts/run.sh
            resources:
              limits:
                huawei.com/ascend-1980: 16
                memory: 512Gi
                ephemeral-storage: 100Gi
              requests:
                huawei.com/ascend-1980: 16
                memory: 512Gi
                ephemeral-storage: 100Gi
                cpu: 125
            ports:
              - containerPort: 8080
            # readinessProbe:
            #   tcpSocket:
            #     port: 8080
            #   initialDelaySeconds: 15
            #   periodSeconds: 10
            volumeMounts:
              - mountPath: /root/.cache
                name: shared-volume
              - mountPath: /usr/local/Ascend/driver/tools
                name: driver-tools
              - mountPath: /dev/shm
                name: dshm
        volumes:
          - name: dshm
            emptyDir:
              medium: Memory
              sizeLimit: 15Gi
          - name: shared-volume
            persistentVolumeClaim:
              claimName: nv-action-vllm-benchmarks-v2
          - name: driver-tools
            hostPath:
              path: /usr/local/Ascend/driver/tools
    workerTemplate:
      spec:
        containers:
          - name: vllm-worker
            imagePullPolicy: Always
            image: swr.cn-southwest-2.myhuaweicloud.com/base_image/ascend-ci/vllm-ascend:nightly-a3
            env:
              - name: CONFIG_YAML_PATH
                value: DeepSeek-V3.yaml
              - name: CONFIG_BASE_PATH
                value: tests/e2e/nightly/multi_node/internal_dp/config/
              - name: WORKSPACE
                value: "/vllm-workspace"
              - name: FAIL_TAG
                value: FAIL_TAG
            command:
              - sh
              - -c
              - |
                bash /vllm-workspace/vllm-ascend/tests/e2e/nightly/multi_node/scripts/run.sh
            resources:
              limits:
                huawei.com/ascend-1980: 16
                memory: 512Gi
                ephemeral-storage: 100Gi
              requests:
                huawei.com/ascend-1980: 16
                ephemeral-storage: 100Gi
                cpu: 125
            volumeMounts:
              - mountPath: /root/.cache
                name: shared-volume
              - mountPath: /usr/local/Ascend/driver/tools
                name: driver-tools
              - mountPath: /dev/shm
                name: dshm
        volumes:
          - name: dshm
            emptyDir:
              medium: Memory
              sizeLimit: 15Gi
          - name: shared-volume
            persistentVolumeClaim:
              claimName: nv-action-vllm-benchmarks-v2
          - name: driver-tools
            hostPath:
              path: /usr/local/Ascend/driver/tools
---
apiVersion: v1
kind: Service
metadata:
  name: vllm-leader
  namespace: vllm-project
spec:
  ports:
    - name: http
      port: 8080
      protocol: TCP
      targetPort: 8080
  selector:
    leaderworkerset.sigs.k8s.io/name: vllm
    role: leader
  type: ClusterIP

    kubectl apply -f lws.yaml

    Verify the status of the pods:

    kubectl get pods -n vllm-project

    Should get an output similar to this:

    NAME       READY   STATUS    RESTARTS   AGE
vllm-0     1/1     Running   0          2s
vllm-0-1   1/1     Running   0          2s

    Verify that the distributed inference works:

    kubectl logs -f vllm-0 -n vllm-project

    Should get something similar to this:

    INFO 12-30 11:00:57 [__init__.py:43] Available plugins for group vllm.platform_plugins:
INFO 12-30 11:00:57 [__init__.py:45] - ascend -> vllm_ascend:register
INFO 12-30 11:00:57 [__init__.py:48] All plugins in this group will be loaded. Set `VLLM_PLUGINS` to control which plugins to load.
INFO 12-30 11:00:57 [__init__.py:217] Platform plugin ascend is activated
INFO 12-30 11:00:57 [importing.py:68] Triton not installed or not compatible; certain GPU-related functions will not be available.
================================================================================================== test session starts ===================================================================================================
platform linux -- Python 3.11.13, pytest-8.4.2, pluggy-1.6.0 -- /usr/local/python3.11.13/bin/python3
cachedir: .pytest_cache
rootdir: /vllm-workspace/vllm-ascend
configfile: pyproject.toml
plugins: cov-7.0.0, asyncio-1.3.0, mock-3.15.1, anyio-4.12.0
asyncio: mode=Mode.STRICT, debug=False, asyncio_default_fixture_loop_scope=None, asyncio_default_test_loop_scope=function
collected 1 item

tests/e2e/nightly/multi_node/internal_dp/scripts/test_multi_node.py::test_multi_node [2025-12-30 11:01:01] INFO multi_node_config.py:294: Loading config yaml: tests/e2e/nightly/multi_node/internal_dp/config/DeepSeek-V3.yaml
[2025-12-30 11:01:01] INFO multi_node_config.py:348: Resolving cluster IPs via DNS...
[2025-12-30 11:01:01] INFO multi_node_config.py:212: Node 0 envs: {'VLLM_USE_MODELSCOPE': 'True', 'OMP_PROC_BIND': 'False', 'OMP_NUM_THREADS': '100', 'HCCL_BUFFSIZE': '1024', 'SERVER_PORT': '8080', 'NUMEXPR_MAX_THREADS': '128', 'DISAGGREGATED_PREFILL_PROXY_SCRIPT': 'examples/disaggregated_prefill_v1/load_balance_proxy_server_example.py', 'HCCL_IF_IP': '10.0.0.102', 'HCCL_SOCKET_IFNAME': 'eth0', 'GLOO_SOCKET_IFNAME': 'eth0', 'TP_SOCKET_IFNAME': 'eth0', 'LOCAL_IP': '10.0.0.102', 'NIC_NAME': 'eth0', 'MASTER_IP': '10.0.0.102'}
[2025-12-30 11:01:01] INFO multi_node_config.py:159: Launching proxy: python examples/disaggregated_prefill_v1/load_balance_proxy_server_example.py --host 10.0.0.102 --port 6000 --prefiller-hosts 10.0.0.102 --prefiller-ports 8080 --decoder-hosts 10.0.0.138 --decoder-ports 8080
[2025-12-30 11:01:01] INFO conftest.py:107: Starting server with command: vllm serve vllm-ascend/DeepSeek-V3-W8A8 --host 0.0.0.0 --port 8080 --data-parallel-size 2 --data-parallel-size-local 2 --tensor-parallel-size 8 --seed 1024 --enforce-eager --enable-expert-parallel --max-num-seqs 16 --max-model-len 8192 --max-num-batched-tokens 8192 --quantization ascend --trust-remote-code --no-enable-prefix-caching --gpu-memory-utilization 0.9 --kv-transfer-config {"kv_connector": "MooncakeConnectorV1", "kv_role": "kv_producer", "kv_port": "30000", "engine_id": "0", "kv_connector_extra_config": {
        "prefill": {
                "dp_size": 2,
                "tp_size": 8
        },
        "decode": {
                "dp_size": 2,
                "tp_size": 8
        }
    }
}

2. Test without Kubernetes#

The same tests/e2e/nightly/multi_node/scripts/run.sh entrypoint can be used on prepared bare-metal or container hosts. Without LWS, set the values that Kubernetes normally injects yourself:

  • cluster_hosts in the config yaml, using IPs reachable from every node.

  • LWS_WORKER_INDEX on each node, starting from 0.

  • CONFIG_YAML_PATH as the config file name and CONFIG_BASE_PATH as the config directory.

Use the host NIC IPs that can reach each other, for example addresses shown by ip addr or ifconfig on the active network interface. Do not use per-host Docker bridge addresses such as 172.17.0.1, because each host has its own local bridge.

Local cluster_hosts edits should be removed before submitting a PR unless the hosts are part of a committed test environment.

2.1 Internal DP local run#

2.1.1 Add cluster hosts#

Edit the internal DP config you want to run, for example:

tests/e2e/nightly/multi_node/internal_dp/config/DeepSeek-V3.yaml

Add cluster_hosts as a top-level field, for example near num_nodes and npu_per_node:

cluster_hosts:
  - "172.22.0.xxx"
  - "172.22.0.xxx"
2.1.2 Prepare the environment#

Install vllm-ascend development dependencies on every cluster host:

cd /vllm-workspace/vllm-ascend
python3 -m pip install -r requirements-dev.txt

Install AISBench on the first host, which is the node with LWS_WORKER_INDEX=0:

export AIS_BENCH_TAG="v3.1-20260330-master"
export AIS_BENCH_URL="https://github.com/AISBench/benchmark.git"
export BENCHMARK_HOME=/vllm-workspace/vllm-ascend/benchmark

git clone -b ${AIS_BENCH_TAG} --depth 1 ${AIS_BENCH_URL} $BENCHMARK_HOME
cd $BENCHMARK_HOME
pip install -e . -r requirements/api.txt -r requirements/extra.txt

If your local image already contains the model, benchmark data, Ascend runtime, and AISBench, you only need the run-time exports in the next step.

2.1.3 Start each node#

Run the script on each node separately. Start worker nodes first, then start node 0.

On node 1:

export WORKSPACE=/vllm-workspace
export IS_PR_TEST=false
export CONFIG_YAML_PATH=DeepSeek-V3.yaml
export CONFIG_BASE_PATH=tests/e2e/nightly/multi_node/internal_dp/config/
export LWS_WORKER_INDEX=1

cd $WORKSPACE/vllm-ascend
bash tests/e2e/nightly/multi_node/scripts/run.sh

On node 0:

export WORKSPACE=/vllm-workspace
export IS_PR_TEST=false
export CONFIG_YAML_PATH=DeepSeek-V3.yaml
export CONFIG_BASE_PATH=tests/e2e/nightly/multi_node/internal_dp/config/
export LWS_WORKER_INDEX=0

cd $WORKSPACE/vllm-ascend
bash tests/e2e/nightly/multi_node/scripts/run.sh

Internal DP logs are mainly printed to the terminal running run.sh. When LOG_PREFIX is set, the shared script also backs up Ascend logs to:

$LOG_PREFIX/node_<LWS_WORKER_INDEX>_plogs/

2.2 External DP local run#

2.2.1 Add cluster hosts#

Edit the external DP config you want to run. For example:

tests/e2e/nightly/multi_node/external_dp/config/GLM5_1-W8A8-EP-external.yaml

Add cluster_hosts as a top-level field, for example near num_nodes and npu_per_node:

cluster_hosts:
  - "172.22.0.xxx"
  - "172.22.0.xxx"
  - "172.22.0.xxx"
  - "172.22.0.xxx"
2.2.2 Prepare the environment#

Install vllm-ascend development dependencies on every cluster host:

cd /vllm-workspace/vllm-ascend
python3 -m pip install -r requirements-dev.txt

Install AISBench on node 0:

export AIS_BENCH_TAG="v3.1-20260330-master"
export AIS_BENCH_URL="https://github.com/AISBench/benchmark.git"
export BENCHMARK_HOME=/vllm-workspace/vllm-ascend/benchmark

git clone -b ${AIS_BENCH_TAG} --depth 1 ${AIS_BENCH_URL} $BENCHMARK_HOME
cd $BENCHMARK_HOME
pip install -e . -r requirements/api.txt -r requirements/extra.txt

If your local image already contains the model, benchmark data, Ascend runtime, and AISBench, you only need the run-time exports in the next step.

2.2.3 Start each node#

External DP uses the same shared run.sh. Set CONFIG_BASE_PATH to the external DP config directory so the script chooses external_dp/scripts/test_external_dp.py.

Then start non-master nodes first, and start node 0 last. The following example uses GLM5_1-W8A8-EP-external.yaml, which is a 4-node disaggregated prefill case.

On node 1, node 2, and node 3, set the matching LWS_WORKER_INDEX:

export WORKSPACE=/vllm-workspace
export IS_PR_TEST=false
export CONFIG_BASE_PATH=tests/e2e/nightly/multi_node/external_dp/config/
export CONFIG_YAML_PATH=GLM5_1-W8A8-EP-external.yaml
export LWS_WORKER_INDEX=1  # Use 2 on node 2, and 3 on node 3.

cd $WORKSPACE/vllm-ascend
bash tests/e2e/nightly/multi_node/scripts/run.sh

On node 0:

export WORKSPACE=/vllm-workspace
export IS_PR_TEST=false
export CONFIG_BASE_PATH=tests/e2e/nightly/multi_node/external_dp/config/
export CONFIG_YAML_PATH=GLM5_1-W8A8-EP-external.yaml
export LWS_WORKER_INDEX=0

cd $WORKSPACE/vllm-ascend
bash tests/e2e/nightly/multi_node/scripts/run.sh

For GLM5_1-W8A8-EP-external.yaml, node 0 and node 1 start prefiller ranks, node 2 and node 3 start decoder ranks, and node 0 also starts the proxy and benchmark.

2.2.4 Read logs while the test is running#

The terminal running run.sh prints pytest orchestration logs. For external DP, AISBench output is also printed on node 0, while rank and proxy stdout/stderr are written to EXTERNAL_DP_LOG_DIR. The default layout is:

/tmp/external_dp_logs/
  node-0/
    rank-0.log
    rank-1.log
    proxy.log
  node-1/
    rank-0.log
    rank-1.log

The first line of each rank log records the exact command and environment used to start that rank. proxy.log exists only on the configured proxy node, usually node 0.

Use a separate log directory when running multiple local experiments:

export EXTERNAL_DP_LOG_DIR=/tmp/external_dp_logs_pd_local

To watch logs in real time, run these commands in another terminal on the corresponding node:

# node 0: ranks and proxy
tail -F /tmp/external_dp_logs/node-0/rank-0.log \
        /tmp/external_dp_logs/node-0/rank-1.log \
        /tmp/external_dp_logs/node-0/proxy.log

# node 1: ranks
tail -F /tmp/external_dp_logs/node-1/rank-0.log \
        /tmp/external_dp_logs/node-1/rank-1.log
