Calibrating Multiple Nodes¶

This procedure explains how to perform calibration for multiple Intel® Gaudi® nodes with more than 8 cards. It requires execution within a Gaudi Pytorch container.

As an example, we use the Llama 3.1 405B model running in tensor parallelism 16 mode spanning two Intel® Gaudi® 2 nodes.

Prerequisites¶

Before you start:

Familiarize with notes and recommendations.
Ensure that all nodes in your multi-node setup are connected to an Network File System (NFS) mount.
Ensure you have a multi-node configuration with more than 8 cards.

Calibration procedure¶

To perform calibration, follow these steps in a Gaudi Pytorch container.

Build and install the latest version of vLLM Hardware Plugin for Intel® Gaudi® by following the Installation procedure.

Create workspace directory on NFS, clone the calibration scripts repository, and create an empty quant_config_buffer.json file in the calibration directory.

mkdir <nfs-mount-path>/my_workspace && cd <nfs-mount-path>/my_workspace
git clone https://github.com/vllm-project/vllm-gaudi
cd vllm-gaudi/calibration
pip install -r requirements.txt
touch quant_config_buffer.json

Check if all Intel® Gaudi® NIC ports are up and running by using the following commands on the host, not inside the container.

cd /opt/habanalabs/qual/gaudi2/bin
./manage_network_ifs.sh --status
# All the ports should be in the 'up' state, you may try flipping the state
./manage_network_ifs.sh --down
./manage_network_ifs.sh --up
# Give it a minute for the NIC to flip and check the status again

Set the following environment variables for all nodes to verify the network interface for inbound and outbound communication.

# Use the 'ip a' or 'ifconfig' command to list all available network interfaces.
export GLOO_SOCKET_IFNAME=eth0
export HCCL_SOCKET_IFNAME=eth0
export QUANT_CONFIG="<nfs-path-to-config>/quant_config_buffer.json"

Start a Ray cluster with enough nodes to accommodate the required tensor parallelism size.

# Start Ray on the head node
ray start --head --port=6379

# Add worker nodes to the Ray cluster
ray start --address='<ip-of-ray-head-node>:6379'

# Check if the cluster has the required number of HPU's
ray status

Run the model calibration script. It will create calibration measurement files in the specified output directory, organized into into subdirectories for each model.

./calibrate_model.sh -m meta-llama/Llama-3.1-405B-Instruct -d <path-to-dataset>/open_orca_gpt4_tokenized_llama.calibration_1000.pkl -o <nfs-path-to-calibration-output>/fp8_output -l 4096 -t 16 -b 128

Optionally, you can reduce the target tensor parallelism level by unifying the measurement scales. For example, you can perform FP8 calibration on the Llama 3.1 405B model using two Intel® Gaudi® 2 nodes with tensor parallelism set to 16, and then use the unification script to reduce the tensor parallelism to 8. To achieve this, you can add the optional -r parameter, to the calibration_model.sh script. This parameter specifies the rank number of the unified measurements. For example, to convert scales from tensor parallelism 16 to 8, set -r 8.
```
./calibrate_model.sh -m meta-llama/Llama-3.1-405B-Instruct -d <path-to-dataset>/open_orca_gpt4_tokenized_llama.calibration_1000.pkl -o <nfs-path-to-calibration-output>/fp8_output -l 4096 -t 16 -b 128 -r 8
```
If you have already performed calibration, you can use the step-5-unify_measurements script to convert existing scales, as in the following example. In this case, the -m <path/ID> parameter has to be set to the calibration output directory containing the measurement files.
```
python3 step-5-unify_measurements.py -r 8 -m <nfs-path-to-calibration-output>/fp8_output/llama-3.1-405b-instruct/g2/ -o <nfs-path-to-calibration-output>/fp8_output/llama-3.1-405b-instruct/g2/
```
If the model contains Mixture of Experts (MoE) layers and is calibrated with expert parallelism, use the -u parameter to unify the original measurement results according to expert parallelism rules, as in the following example:
```
python3 step-5-unify_measurements.py -r 4 -m <nfs-path-to-calibration-output>/fp8_output/model_name/g2 -o <nfs-path-to-calibration-output>/fp8_output/model_name/g2 -u
```

Serve the FP8 quantized model.

export QUANT_CONFIG='<nfs-path-to-calibration-output>/fp8_output/llama-3.1-405b-instruct/maxabs_quant_g2.json'
vllm serve meta-llama/Llama-3.1-405B-Instruct --quantization inc --kv-cache-dtype fp8_inc --tensor-parallel-size 8 --max-model-len 2048

Recommendations for Advanced Usage for MoE Models¶

For models with Mixture of Experts (MoE), such as DeepSeek-R1, you can run the calibration once and reuse the results across different expert parallelism and data parallelism configurations, for example, 8, 16, or 32 cards. This process requires:

Unifying all measurement files onto a single card (TP1).
Optionally, postprocessing the unified measurements to improve performance.
Expanding the unified results to the desired number of expert-parallel cards. The step-6-expand-measurements script distributes the expert measurements across the target number of cards, while other values are reused.

The following diagram presents an example in which calibration is performed on 2 cards and deployment occurs on 4 cards.

The following example demonstrates calibration with DeepSeek-R1 on 8 cards, followed by deployment on 16 and 32 cards.

# Unify measurements: TP8 -> TP1
python step-5-unify_measurements.py -m /path/to/measurements/deepseek-r1/g3/ -r 1 -o /path/to/measurements/deepseek-r1/g3-unified-tp1/ -u -s

# (Optional) Postprocess unified TP1
python step-3-postprocess-measure.py -m /path/to/measurements/deepseek-r1/g3-unified-tp1/ -o /path/to/measurements/deepseek-r1/g3-unified-tp1-post/ -d

# Expand to EP16TP1
python step-6-expand-measurements.py -m /path/to/measurements/deepseek-r1/g3-unified-tp1-post/ -o /path/to/measurements/deepseek-r1/g3-unified-tp1-post-expand-ep16 -w 16

# Expand to EP32TP1
python step-6-expand-measurements.py -m /path/to/measurements/deepseek-r1/g3-unified-tp1-post/ -o /path/to/measurements/deepseek-r1/g3-unified-tp1-post-expand-ep32 -w 32
